Cable Coil Wrapping Machine
This series cable coil wrapping machine mainly designed for cable industries could be widely used in the outside wrapping of different sized cable coils and other circular articles such as hose coils, pipe coils, wire coil material and so on.
Description
CABLE COIL WRAPPING MACHINE
This series cable coil wrapping machine mainly designed for cable industries could be widely used in the outside wrapping of different sized cable coils and other circular articles such as hose coils, pipe coils, wire coil material and so on.
The wrapped cable coils is closely wrapped by the stretch film, which is not only beautiful in looking, but also tidy and safe for storage and transports. Easy operation but with extremely high packing efficiency and low cost.
BASIC FEATURES:
1. The cable coil wrapping machine is in horizontal state convenient for manual handling and operating.
2. Superior collections with good quality and famous brands adopted for main components.
3. The running speed or the ring and the carrier rollers are able to be changed by converters.
4. Integrated electrical control panel for easy operation and space saving.
5. Ring jog, reset, soft start and stop functions.
6. Tension of the wrapping tape is able to be adjusted.
7. Fixing device adopted to avoid coil shaking in wrapping.
8. The overlapping degree of the wrapping film can be adjusted through frequency converters.
9. Simply structure, very easy to operate and maintenance.
MAIN PARAMETERS:
Model | GW200 |
Structure | Horizontal |
Packing objects | Cable coils |
Coil width | ≤200mm |
Coil ID | ≥150mm |
Coil OD | ≤450mm |
Coil weight | ≤300kg |
Ring speed | 10-90r/min |
Roller speed | 5-8m/min |
Packing material | Stretch film/VCI film,etc Width:60-90mm; core ID: 50mm; OD: 100-200mm |
PE film/knit tape/compound paper tape/crepe paper,etc Width:60-90mm, core ID: 55mm, OD: 100-500mm | |
Power output | Appr. 2.0kw |
Power voltage | 220V/380V, 50HZ/60HZ |
Air supply | 6~8kgf/cm2 |
Synchronous wrapping system | Optional |
Automatic mechanical hand | Optional |
HMI touch screen | Optional |
Roller conveyor | Optional |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
OPERATIONS:
1. Rotate the“POWER”switch clockwise to connect to the power supply.
2. Rotate the“EMERGENCY STOP”switch clockwise.
3. Hoist the unpackaged object onto the working station, and adjust the protective rollers effectively.
4. Fix Packing tape on the unpacked object.
5. Set the“cutting time”as per different object in the control panel, normally between 3-10 seconds.
6. Press the“RING START”button to run the machine.
7. The machine will stop automatically after a packing process is completed. Cut the packing tape manually and fix it onto the object.
8. Move the package away, thus one packaging is completed.
AFTER-SALES SERVICE GUARANTEE
1. One year for warranty
A. Supply the spare parts of the machine for free.
B. If need, engineers available to service machinery overseas.
C. Change the broken parts of electric components for free.
D. Respond and deal with the trouble of the machine within 3 hours after receiving technical supportive requirement.
E. A new machine will be as a replacement, if the machine still can’t work after maintenance.
2. 10 years warranty for structure fame
3. Our engineer will be arrived at your site within one week according to Visa, if need be.
4. Lifelong technical assistance and support
