Electrical Cable Wrapping Machine

Name: China Electrical Cable Wrapping Machine Suppliers and Manufacturers - Cheap Price Electrical Cable Wrapping Machine - Jinglin
Brand: Jinglin
SKU: 58009753

Jinglin is engaged in offering customized packing solutions adapt to different needs for all the rubber and plastic industries for 20 years. The electrical cable coil wrapping machine works in an horizontal state,to make the cable coils tightly sealed by stretch film, looks neat and beautiful in packaging and tidy and safe for storage and transports. High packing efficiency, but have low labor cost and material costs.

Send Inquiry

Description

Electrical cable wrapping machine

APPLICATION:

BASIC FEATURES:

1. Simple design of machine, safe and convenient operation.

2. Well known brands adopted for main components in the cable wrapping machine.

3. Over lap extent degree is adjustable by inverters per requirements.

4. The wrapping film tension adjustable.

5. Pressing and side rollers are adopted to fix the coil position.

6. Integrated electrical box for space saving and convenient operation.

7. PLC and HMI systems can be adopted for automatic program setting and calculate the usage of the packing material by entering ID, OD, width automatically and easily.

8. Synchronous wrapping device is available for choose for wrapping two material together.

MAIN PARAMETERS:

ITEMS	GW300
Object	Cable coils/hose coils
Package width	≤300mm
Package OD	300-600mm
Package ID	≥250mm
Rotating speed	About 20-90r/min
Overlap scope	30%-70%
Material	Knit tape/stretch film/compound paper etc. W:100mm OD:≤300mm ID:55mm
Power output	About 1.5kw
Power voltage	380V/50Hz /3 phase
Synchronous wrapping system	Optional
Automatic mechanical hand	Optional

Note: the datas are only for reference, the machine can be custom designed according to specific object size.

TROUBLESHOOTING:

Problem	Possible cause & solution
I. The complete machine doesn’t work.	1. Check external power supply and power switch.
II. The ring doesn’t rotate or rotates abnormally.	1. Check the wear of friction wheel. If it is seriously worn, new friction wheel shall be replaced. 2. Adjust the friction force of the friction wheel to the ring.
IV. The ring and roller don’t work.	1. Check power supply. 2. Check whether there is problem with the convertor. 3. Check whether the friction wheels get stuck.
V. Packaging tape is misaligned or multi-folded.	1. Check whether the feeding route of packaging tape is on one straight line. 2. Check whether the tape storing wheel on the ring is damaged 3. May be caused by the packing tape quality. High-quality packaging tape shall be replaced.
