Hose Coil Packing Machine

The vertical hose coil packing machine with ring top opening structure is normally for packaging of light or small corrugated hose coils and pipe coils, with a pressing roller to fix the coil position from movement. The machine is with a high working table for convenient operation of the operator. The common wrapping material matched with this machine is LLDPE stretch film.

Send Inquiry

Description

HOSE COIL PACKING MACHINE

MACHINE APPLICATION:

CHARACTERISTICS:

1. The packing machine designed with a high packing table easier for manual operation.

2. Over lap degree of the film could be adjusted in accordance with requirement.

3. The board height with turning ring could be adjusted.

4. Wrapping material tension could be adjusted.

5. Side rollers adopted for protect the coils from shaking during packing.

6. The supporting rollers covered by polyurethane are adopted to fix the coil.

7. Separate electrical box for safe operation and trouble-shooting.

9. Safety covers for moving parts of the hos coil wrapping machine.

10. Simple structure, easy operation and maintenance.

TECHNICAI DATA:

ITEMS	GD200	GD300
Object	Hose coils/pipe coils	Hose coils/pipe coils
Package width	≤200mm	≤300mm
Package OD	300-500mm	300-600mm
Package ID	≥200mm	≥250mm
Rotating speed	About 20-90r/min	About 20-90r/min
Roller speed	2-4m/min	2-4m/min
Overlap scope	10%-90%	10%-90%
Wrapping Material	LLDPE/PE/Stretch film/PVC W:80mm OD:≤120mm ID:50mm	LLDPE/PE/Stretch film/PVC W:80mm OD:≤120mm ID:50mm
Power output	About 1.0kw	About 1.5kw
Power voltage	380V/50Hz /3 phase	380V/50Hz /3 phase

Note: the datas are only for reference, the machine can be custom designed according

to specific object size.

Machine Installation:

1. This hose coil packing machine is composed of the main wrapping machine and electrical cabinet, safety covers, etc.

2. Place the machine on the ground surface horizontally, then install other parts and small auxiliaries.

3. As the machine has been transported and moved, all flexible components shall be inspected carefully.

4. The entire installation shall be completed under the power supply is cut off.

5. The hose coil wrapping machine shall be mounted on flat and hard ground; The power supply should comply with stated in the nameplate of the machine.

6. The machine shall be mounted in dry and dust free environment.

AFTER-SALES SERVICE

*12 months warranty for whole machine

*FREE spare parts of the machine

*Quick technical respondence within 24 hours upon receiving request

*10 years warranty for structure fame

*Overseas maintenance available if needed

*New machine replacement available for irreversible quality issue
