Automatic Wire Wrapping Machine
The automatic wire wrapping machine made by Shanghai Jinglin is designed mainly for coiled objects especially for steel coils, wire coils,copper coils,pipe coils,etc. It can effectively protect your products and play a role of waterproof, dustproof, antirust, anti-damaging,anti-aging. The machine can not only help you save the labor force, save space in your warehouse, improve your working efficiency,but also can well decorate your package objects.
Description
AUTOMATIC WIRE WRAPPING MACHINE
SUMMARIZE:
The automatic wire wrapping machine made by Shanghai Jinglin is designed mainly for coiled objects especially for steel coils, wire coils,copper coils,pipe coils,etc. It can effectively protect your products and play a role of waterproof, dustproof, antirust, anti-damaging,anti-aging. The machine can not only help you save the labor force, save space in your warehouse, improve your working efficiency,but also can well decorate your package objects.
APPLICATIONS:
1. Steel wire coil
2. Galvanized Iron wire coil
3. Pre-stressed wire coil
4. Stainless wire coil
5. Copper wire coil
6. Razor wire coil
7. Binding wire coil
8. Wire rod
INSTALLATION:
The machine shall be mounted on flat & hard ground, where the ground load should be more than 1 ton/m2.
BASIC FEATURES:
1. Scientific design, high packing efficiency with less energy and material consumption.
2. Moving trolley for safe handling and loading the wire coils.
3. PLC adopted for automatic program control.HMI for simple operation.
4. Overlapping degree and tension of the wrapping material tension can be adjusted.
5. The ring&roller speed can be adjusted through the converters.
6. Ring height of the wrapper could be adjusted for different wire ID&OD.
7. Anti-wearing polyurethane is adopted for the friction wheel.
8. The carrier rollers and protective rollers are wrapped with poly urethane.
9. Indication lights alarm automatically upon trouble occurs.
10. Soft start, soft stop and precise reset of the ring.
MAIN PARAMETERS:
Model | GD300 | GD600 | GD800 |
Coil width | ≤300 | 150mm-600mm | 400mm-800mm |
Coil OD | ≤1500 | 800mm-1600mm | 1000mm-1900mm |
Coil ID | 508/610mm | 508mm/610mm | 508mm/610mm |
Coil weight | ≤2000Kg | 300kg-6000Kg | 1000Kg-12000kg |
Ring speed | Appr. 20-90r/min | Appr. 20-80r/min | Appr. 20-60r/min |
Roller speed | 5-8m/min | 5-8m/min | 5-8m/min |
Power output | 2.0KW | 3.5KW | 4.5KW |
Power supply | AC/380V/50Hz | AC/380V/50Hz | AC/380V/50Hz |
Air supply | 6-8kgf/cm2 | 6-8kgf/cm2 | 6-8kgf/cm2 |
Packing material | Knit tape/compound paper/VCI paper/etc: width:80-100mm; ID:55mm; OD≤500mm | Knit tape/compound paper/VCI paper/etc: width:80-100mm; ID:55mm; OD≤500mm | Knit tape/compound paper/VCI paper/etc: width:80-100mm; ID:55mm; OD≤500mm |
Stretch film: width:80-100mm; ID:50mm; OD≤150mm | Stretch film: width:80-100mm; ID:50mm; OD≤150mm | Stretch film: width:80-100mm; ID:50mm; OD≤150mm | |
Synchronous wrapping system | Optional | Optional | Optional |
Automatic manipulator | Optional | Optional | Optional |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
SUPPLY LIST:
No. | Description of Item | Quantity |
1 | Main engine of the wrapping machine | 1set |
2 | Cutter board, film release device etc. | 1set |
3 | Electrical control cabinet, guardrail etc. | 1set |
4 | Trolley with track for loading&unloading | 1set |
5 | Operation manual and spare parts | 1set |
