Orbital Wrapping Machine

The orbital wrapping machine is a rotating ring machine for spiral wrapping elongated or any horizontal products especially for pipes, profiles, bars, panels,and etc.The stretch wrapper is able to protect the products from damage during handling, transportation and storage.The stretch wrapping machine enables superior product protection, faster and more effective packaging, and also greatly reduce materials consumption and energy consumption.

Send Inquiry

Description

ORBITAL WRAPPING MACHINE

APPLICATION:

INSTALLATION:

The machine shall be mounted on flat & hard ground, where the ground load should be more than 1 ton/m².

BASIC FEATURES:

1. Wrapping Station:

*Double-ring and double-rub wheel system make work safe, stable & energetic.

*Friction between driving wheels and ring is adjustable.

*Speed of the ring is adjustable by inverter.

*Wrapping position reset function.

*Packing material tension could be adjusted.

*Protect guardrail ensure safe operation.

*Material overlapping is adjustable from 10%-90%

2. Conveyor System:

*Automatic entrance conveyor and outlet conveyor system.

*Conveyor adjustment by inverters.

*Conveyors driven by motor with gear box.

*Speed of the conveyors is adjustable by inverter.

*Sensor detecting the objects for operation action.

3. Automatic protective System:

*Automatic protective devices to avoid products shaking in wrapping.

*Pressing down device and supportive rollers for fix the packing position.

*The action time is adjustable for difference packing purpose.

4. PLC&HMI control system :

*PLC and program enable machine to do automatic wrapping.

*Indicator alarms automatically when trouble occurs. Trouble can be shown automatically by touch screen.

*Separate control panel makes operation & maintenance easily.

*Interface operation.

5. Automatic mechanical feeding&cutting system(optional):

*It enable the automatic operation of the machine.

*Both automatic operation and manually mode.

*Automatic material feeding and cutting for film.

*Action time adjustable.

6. Length of the conveyor (Optional)

*Length of conveyor is optional for your requirement.

MAIN PARAMETERS:

Items	GG300	GG500
Section diameter of the object (φ)	≤300mm	≤500mm
Object length	Not limited	Not limited
Conveyor length	1000-6000mm	1000-6000mm
Conveying speed	About 1-10m/min	About 1-10m/min
Rotating speed	20-90r/min	20-90r/min
Conveyor height	Appr. 1000mm	Appr. 1000mm
Overlap scope	About 10%-90%	About 10%-90%
Power output	About 1.5kw	About 2.0kw
Power voltage	380V/3phase/ 50Hz	380V/3phase/ 50Hz
Material	Compound paper tape/knit tape/anti-rust tape/ stretch film Roll width:≤250mm Max OD:400mm ID:55mm	Compound paper tape/knit tape/anti-rust tape/ stretch film Roll width:≤250mm Max OD:400mm ID:55mm
