FZ-03 Coil Tilter

Jinglin is able to offer you a complete choice of tilters which include mechanical coil tilters and hydraulic coil tilters for tilting steel coils from eye vertical position to horizontal position or vice versa.

Send Inquiry

FZ-03 COIL TILTER

MACHINE APPLICATION:

Jinglin is able to offer you a complete choice of tilters which include mechanical coil tilters and hydraulic coil tilters for tilting steel coils from eye vertical position to horizontal position or vice versa.

The FZ-03 coil tilter is used for tilting heavy objects with different specifications for 90 degree with max loading capacity 3tons. It’s widely used in industries of metallurgy, stamping, metal plate, mold, paper making, steel strip, coil, barrels, and etc. High efficient working, safe and reliable.


BASIC FEATURES:

1) Special double chain drive, oblique gear and worm speed reducer.


2) Reasonable four-roller device for object holding makes tuning smooth and steady.


3) Independent electrical panel control for easy and safe operation.


4) Micrometric setting for adjusting the floor level.

5) Converter controls, Fast, stable and safe.


6) Both electric & mechanical limit restrictors adopted to grantee safe operation.

7) The machine can be stopped at any angle during turning.

8) Emergence stop and position locking function avoid rotation.

9) The machine will stop automatically when turning process finished.

10) Emergency stop button can stop the machine rapidly in emergency conditions.


MAIN PARAMETERS:

Item \data

FZ-03

Max loading

3T

One-way turn-over speed

Approx. 30s

Transfer mode

Mechanical

Power output

1.5KW

Working mode

Manual switch/ remote control

Product width

600mm

Product diameter

1500mm

Product weight

Within 3000kg

Dimension

Approx. L2200mm/W1000/H1700mm

Power voltage

AC 380V, 3 phase 5wires

Note: the datas are only for reference, the machine can be custom designed according to specific object size.
