Hydraulic Hose Wrapping Machine
The GW series hydraulic hose wrapping machine is particularly designed for realize tight and close packing needs for hose coils, pipe coils, and other coiled objects horizontally. The wrapped hose coils are perfectly sealed and looks tidy and beautiful for storage, transportation and market. Easy operation, low energy and material consumption, but with high packing efficiency and few labor cost.
Description
HYDRAULIC HOSE WRAPPING MACHINE
The GW series hydraulic hose wrapping machine is particularly designed for realize tight and close packing needs for hose coils, pipe coils, and other coiled objects horizontally. The wrapped hose coils are perfectly sealed and looks tidy and beautiful for storage, transportation and market. Easy operation, low energy and material consumption, but with high packing efficiency and few labor cost.
BASIC FEATURES:
*The hose packing machine is in horizontal structure with a working table convenient for manual handling.
*Suitable for pack light coils which are easy to load and offload by manual.
*Overlapping rate and film tension able to be adjusted according to needs.
*Different packing material can be chose.
*Indication lights alarm automatically when trouble appears.
*The carrier rollers wrapped with polyurethane to protect the product surface.
*Safe fence for turning parts ensure safe operation.
*Automatic material feeding and cutting is available for choose.
*The main wrapper engine can be designed moveable for convenient loading of heavy coils.
*Conveyors can be equipped for automatic operation.
MAIN PARAMETERS:
ITEMS | GW200 | GW300 |
Coil height | ≤200mm | ≤300mm |
Coil OD | 300-500mm | 300-600mm |
Coil ID | ≥200mm | ≥250mm |
Ring speed | About 20-90r/min | About 20-90r/min |
Overlap ratio | 20%-90% adjustable | 20%-90% adjustable |
Material | Woven plastic tape/stretch film/compound paper&etc. W:100mm OD:≤300mm ID:55mm | Woven plastic tape/stretch film/compound paper&etc. W:100mm OD:≤300mm ID:55mm |
Output | About 1.0kw | About 1.5kw |
Power voltage | 380V/50Hz /3 phase | 380V/50Hz /3 phase |
Synchronous wrapping system | Optional | Optional |
Automatic mechanical hand | Optional | Optional |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
INTRODUCTION TO THE OPERATING PANEL SWITCH:
POWER: The main switch of machine power supply which is used to connect or shut off the machine power supply.
EMERGENCY STOP: The control switch which is used to control circuit. Press to shut down the machine in case of emergency.
START: Press the button to make the ring working.
STOP: Press the button to make the ring stopped
RING RESET: Reset the ring, make the in& out of the object convenient.
ROLLER（FWD/REV）:Used to put the roller under clockwise or anticlockwise when ring starts running.
RING JOG: Press the button, the ring runs slowly, and will stop when looses the button. Used to check if the ring runs through the coil center.
TIME: cutting time set. The packing material will be cut automatically after the set time. Adjust the time according to needs.
AFTER-SALES SERVICE
12 months warranty for whole machine
FREE spare parts of the machine
Quick technical respondence within 24 hours upon receiving request
10 years warranty for structure fame
Overseas maintenance available if needed
New machine replacement available for irreversible quality issue
CERTIFICATE
CE Approved
IEC PROTECTION
IP54
