STRETCH FILM WRAPPING MACHINE

MACHINE APPLICATION:

The cylindrical stretch film wrapping machine is specially designed for stretch wrapping of one or multiple cylindrical objects; it’s applicable for both light and heavy product, to make it dust-proof, water-proof,well protected and decorated. Different packing type of automatic online packing, compound packing, independent packing can be chose according to actual packing needs.

BASIC OPERATION:
1. Manually lift the non-woven roll to the packing station and prepare for packaging. After the packaging is completed, the ejection system of the packing position will push out the roll. Offload the packed roll and start the next packing operation.
2. The initial film feeding, fixing and film cutting at the end are completed by manually.

MAIN PARAMETERS:

*PLC is adopted for electrical control,can set the wrapping circles freely.

*Can set special wrapping position reinforcement (top, middle, and bottom).

*The packing length is adjustable.

*Pre-stretch film carriage structure for uniform wrapping, beautiful packaging and strong adaptability.

*Photoelectric for automatic tracking packaging length, accurate positioning.

*Variable frequency control of roller, the overlapping degree of film can be adjusted as required.

*Automatic ejection of goods, convenient for unloading.

*Automatic fault alarm, automatic display of the fault content.

*Simple design, easy operation and convenient maintenance.

*Can start, stop, positioning freely.

TECHNICAL PARAMETERS:

*Model: JL2100-R

*Type: cylindrical type wrapping machine

*Work mode: Auto

*Object size: Ф(400-1200)

*Max packing length: 500-1600mm

*Max packing weight: 2000kg

*Packing speed: 20-40roll/hour

*Film carriage system: Pre-stretch film carriage/stretch ratio 250%

*Automatic film feeding/speed adjustable

*Supply voltage: AC380V/50HZ/three phase five wire

Note: the datas are only for reference, the machine can be custom designed according to specific object size.
