Profile Packing Machine

The profile packing machine can be widely applied in the exterior wrapping of different sized aluminium profiles, wooden profiles and other types of horizontal profiles, to meet the high packing efficient requirements of profile manufacturers. The wrapped package is well-protected & sealed & looks tidier.

Description

PROFILE PACKING MACHINE

MACHINE APPLICATION:

The profile packing machine can be widely applied in the exterior wrapping of different sized aluminium profiles, wooden profiles and other types of horizontal profiles, to meet the high packing efficient requirements of profile manufacturers. The wrapped package is well-protected & sealed & looks tidier.


FEATURES:

1. PLC & HMI are adopted.

2. Indicator alarms automatically when trouble occurs.

3. Friction wheel mechanism makes working more safe stable & energetic.

4. Rollers, belt and shelf can be chose for conveyor lines.

5. Photocell sensor is adopted for setting packing position.

6. Special tension device adopted.

7. Height of the ring could be adjusted for different object.

8. Manipulator could be opted for film feeding and cutting, safe and efficient.

9. Press roller and side protective roller could be adopted for single profile or light object fixing .

10. Short objects can also be wrapped as the machine has a wide application.


TECHNICAL PARAMETERS:

Model

GG200

Object length

300 mm-1000mm

Object width

50-200mm

Object thickness

50-200mm

Weight

10-100KG

Conveyor speed

4-9m/min

Ring speed

30r/min-80r/min adjustable

Packing speed

25-45s/pcs

Overlap rate

10%-90%

Conveyor mode

Belt conveyor or roller conveyor

Packing material

Stretch film

Material size

 ID:76mm; OD:80-150mm; width:90mm

Note: the datas are only for reference, the machine can be custom designed according to specific object size.
