FZ-20 Hydraulic Upender

FZ-20 HYDRAULIC UPENDER

MACHINE APPLICATION:

The FZ-20 hydraulic upender is driven by hydraulic cylinder to make the heavy products turning over for 90 degrees. The tilter can widely used in different industrial such as steel coils, aluminium coils, wire coils, copper coils, molds, paper rolls, spools&etc.

BASIC FEATURES:

1) Solid structure, firm and durable.

2) Hydraulic driven makes the turning operation more smooth and reliable.

3) Multiple limit protection makes the machine safer.

4) Two-way backpressure technique, ensure smooth transition during object shifting.

5) Independent remote control, ensure convenient and safe operation.

6) Smooth, accurate, vibration-free motion.

7) The machine can be stopped at any angle during turning.

8) The machine stops automatically when turning finished.

9) Can turn-over and reset, work in circle.

10) Emergency stop button can stop the machine rapidly in emergency conditions.

MAIN PARAMETERS:

Note: the datas are only for reference, the machine can be custom designed according to specific object size.

EQUIPMENT PAINTING:

1) The whole machine should be painted for two times.

2) The machine should be painted anti-corrosive primer firstly, and the color of surface painting can be adopted as required.

3) Color of tilter body: yellow. Color of electrical cabinet: RAL 7035.

SCOPE OF SUPPLY:
