Automatic Bearing Packing Machine
Jinglin designed the series of horizontal bearing packing machine for through-eye wrapping of various bearings by stretch film, compound paper, VCI paper&etc to achieve the closed and protective packing and to simplify the wrapping procedure and lessen the labor density, it’s suitable for both small and large size bearings. The machine can be connected with associated production line to or operated independently.
Description
HORIZONTAL BEARING PACKING MACHINE
Jinglin designed the series of horizontal bearing packing machine for through-eye wrapping of various bearings by stretch film, compound paper, VCI paper&etc to achieve the closed and protective packing and to simplify the wrapping procedure and lessen the labor density, it’s suitable for both small and large size bearings. The machine can be connected with associated production line to or operated independently.
CHARACTERISTICS:
1. Horizontal structure with motorized conveyors for efficient packing.
2. Flexible wrapping table specially designed for turning of bearings.
3. PLC and HMI for automatic operation.
4. The tension and overlapping degree of wrapping material can be adjusted.
5. Photo sensors for automatic coil positioning.
6. Different packing material can be chose.
7. Packaging tension is adjustable by special breaker.
8. Independent control cabinet easy for operation and maintenance.
9. Automatic material feeding and cutting is available.
10. Safe guardrails for turning part ensure safe operation.
11. The rollers wrapped by polyurethane to protect the products.
12. Conveyors length can be customized.
MAIN PARAMETERS:
Mode | ZC100 | ZC200 | ZC300 | ZC400 |
Type | Horizontal | Horizontal | Horizontal | Horizontal |
Object width | ≤100mm | ≤200mm | ≤300mm | ≤400mm |
Object ID | ≥150mm | ≥250mm | ≥400mm | ≥400mm |
Object OD | ≤500mm | ≤700mm | ≤1300mm | ≤2000mm |
Object weight | ≤100kg | ≤300kg | ≤500kg | ≤1000kg |
Ring speed | 10-100r/min | 10-100r/min | 10-100r/min | 10-100r/min |
Roller speed | 1-3m/min | 1-3m/min | 1-3m/min | 1-3m/min |
Packing material | Stretch film/VCI film,etc Width: 50-60mm; core ID: 50mm; OD: 100-200mm | Stretch film/VCI film,etc Width: 50-60mm; core ID: 50mm; OD: 100-200mm | Stretch film/VCI film,etc Width: 50-60mm; core ID: 50mm; OD: 100-200mm | Stretch film/VCI film,etc Width: 50-60mm; core ID: 50mm; OD: 100-200mm |
PE film/knit tape/compound paper tape/crepe paper,etc Width:50-60mm, core ID:55mm,OD: 100-500mm | PE film/knit tape/compound paper tape/crepe paper,etc Width:50-60mm, core ID:55mm,OD: 100-500mm | PE film/knit tape/compound paper tape/crepe paper,etc Width:50-60mm, core ID:55mm,OD: 100-500mm | PE film/knit tape/compound paper tape/crepe paper,etc Width:50-60mm, core ID:55mm,OD: 100-500mm | |
Output | Appr. 1.5kw | Appr. 1.5kw | Appr. 1.5kw | Appr. 1.5kw |
Supply voltage | 220V/380V, 50HZ/60HZ | 220V/380V, 50HZ/60HZ | 220V/380V, 50HZ/60HZ | 220V/380V, 50HZ/60HZ |
Air supply | 6～8kgf/cm2 | 6～8kgf/cm2 | 6～8kgf/cm2 | 6～8kgf/cm2 |
Automatic mechanical hand | Optional | Optional | Optional | Optional |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
*12 months warranty for whole machine
*FREE spare parts of the machine
*Quick technical respondence within 24 hours upon receiving request
*10 years warranty for structure fame
*Overseas maintenance available if needed
*New machine replacement available for irreversible quality issue
CERTIFICATE
CE Approved
IEC PROTECTION
IP54
