Copper Bar Wrapping Machine
This copper bar wrapping machine specialized for long and straight products, such as copper bar, steel bars,plastic pipes, profiles, sheets, board, etc. The wrapped package is well decorated, protected and well for storage and transport. The machine can be connected to your existed production line, which plays a key role in your production procedure and is popular in modern packaging industry.
Description
COPPER BAR WRAPPING MACHINE
MACHINE APPLICATION:
This copper bar wrapping machine specialized for long and straight products, such as copper bar, steel bars,plastic pipes, profiles, sheets, board, etc. The wrapped package is well decorated, protected and well for storage and transport. The machine can be connected to your existed production line, which plays a key role in your production procedure and is popular in modern packaging industry.
MAIN PARAMETERS:
Items | GG300 | GG500 |
Section diameter of the object | ≤300mm | ≤500mm |
Package length | Not limited | Not limited |
Conveyor length | 1000-6000mm | 1000-6000mm |
Conveying speed | About 1-10m/min | About 1-10m/min |
Rotating speed | 20-90r/min | 20-90r/min |
Conveyor height | Appr. 800mm | Appr. 800mm |
Overlap scope | About 10%-90% | About 10%-90% |
Power output | About 1.5kw | About 2.0kw |
Power voltage | 380V/3phase/ 50Hz | 380V/3phase/ 50Hz |
Material | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film |
Material size | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm |
OPERATIONS:
(1) Connect the power supply and rotate the total POWER switch.
(2) Rotate EMERGENCY STOP switch and the red indication light is on.
(3) Select “AUTO”working mode on the operating panel.
(4) Hoisting the unpackaged bars on the central position of the front conveyor.
(5) Press Convey line button, the conveyor line runs. Stop it at the wrapping position.
(6) Fix the packing material on the object.
(7) Press START button, the ring rotates automatically and stops automatically.
(8) After a packaging process is finished, use adhesive tape to fix the tail of packing tape.
(9) Press Convey line button to transfer the packed object away from working station for unloading.
