Aluminium Profile Packing Machine
The aluminum profile packing machine is engineered to wrapping the aluminium profiles automatically by stretch film, plastic knit tape or other compound materials needed, the object can be a single profile or profile bundle.
Description
ALUMINUM PROFILE PACKING MACHINE
MACHINE APPLICATION:
The aluminum profile packing machine is engineered to wrapping the aluminium profiles automatically by stretch film, plastic knit tape or other compound materials needed, the object can be a single profile or profile bundle.
The machine can be special designed based on the customer’s profile specification, both small and big profiles can be packed by one machine. Please contact us for more details.
FEATURES:
*PLC programmable control and HMI screen operate.
*Alarming automatically for machine errors.
*Friction structure adopted for safe, steady and strong operation.
*Photocell sensor adopted for automatic object tracking.
*Special tension adjust system ensures uniform tension of the wrapping material.
*Protective rollers wrapped by PU.
*Turning ring height is adjustable.
*Independent control cabinet, convenient for operation and maintenance.
*Conveyor length can be customized.
*Mechanical hand can be chosen for automatic film feeding & cutting.
*Two different material can be wrapped synchronously (optional).
TECHNICAL PARAMETERS:
Item\data | GG400 |
Product length | 1500-6000mm |
Max OD | 400 mm |
Loading capacity | 1000KG |
Ring speed | Approx. 90r/min |
Conveying mode | Roller or belt |
Conveyor length | 6000mmx2 or according to requirement |
Convey speed | 6-12m/min |
Conveyor height | 750mm |
Wrapping material | Compound paper tape/ woven belt//stretch film/ non-woven fabrics etc |
Wrapping material size | Width: 150-200mm OD: 250mm, ID:55mm |
Power output | App.2.5KW |
Power voltage | AC/380V/3 Phase 5 line |
Manipulator | optional |
Note: the datas are only for reference, the machine can be custom designed according to specific object size.
OUR PRODUCTS AVAILABLE:
Steel/aluminum/cable/wire/copper/pipe/tyre coil type wrapping machine;
Horizontal pipe/tube/profile/bar/door wrapping machine;
Stretch pallet wrapping machine;
Automatic steel/copper/aluminium coil packing line;
Automatic plastic pipe bundling& packing line;
Automatic steel tube bundling& packing line;
Automatic coil tilter;
Other customized packing machines.
COMPANY ADVANTAGES:
1. Advanced technology
2. Complete products
3. Rich experience
4. Excellent service
5. Outstanding innovation
